Descrizione tecnica

Technical description

La porta Aura con sistema

di chiusura magnetica a scom-

parsa è dotata di un profilo

di battuta in gomma siliconica,

che assicura silenziosità e affi-

dabilità nel tempo.

Le versioni battente e scor-

revole presentano uno stipite

telescopico in alluminio

anodizzato o verniciato che

permette di compensare

lo spessore di eventuali rive-

stimenti, con un'escursione

massima di 15 mm per lato.
