Cert. No. LRQ 0963008

ISO 9001

Description

IFT14

Ball Float Steam Trap

with Integral Spiratec Sensor

The IFT14 is an SG iron bodied ball float steam trap having

stainless steel working internals, integral Spiratec sensor and

automatic air venting facility. It can be supplied with either a

WLS1 sensor to detect waterlogging and steam leakage or a

SS1 sensor for steam leakage only. The IFT14 is supplied with

horizontal connections, having flow from right to left (R – L), and

can be simply integrated into all existing Spiratec monitoring

systems.

Capsule

The BP99 / 32 capsule which is used in the FT14 is suitable for use

on 150°C superheat @ 0 bar g and 50°C superheat @ 32 bar g.

Standards

The product fully complies with the requirements of the European

Pressure Equipment Directive 97/23/EC.

Certification

This product is available with a manufacturers' Typical Test Report.

Note: All certification/inspection requirements must be stated at

the time of order placement.

2

1

3

4

17

Sizes and pipe connections

1⁄2" and 3⁄4" screwed BSP or NPT.

Pressure/temperature limits (ISO 6552)

The product should not be used in this region due to the

limitations of the sensor.

���

���

���

���

5.5.6

Steam

saturation curve

24

Materials

No. Part

1

Body

2

Cover bolts

3

Cover gasket

4

Cover

* 5

Valve seat

* 6

Valve seat gasket

* 7

Pivot frame

assembly screws

8

Ball float and lever

* 10 Pivot frame

* 11 Pivot pin

17 Air vent assembly

* 18 Air vent seat gasket

24 Sensor

25 Sensor gasket

25

8

Material

SG iron

Steel

Steam traps

Ball float

Page 1 of 3

TI-P615-01

ST Issue 6

T

e

m

p

e

r

a

t

u

r

e

°

C

��

�

�

�

�

�

�

��

��

��

��

Pressure bar g

DIN 1693 GGG 40

BS 3692 Gr. 8.8

The product must not be used in this region.

Body design conditions

SG iron

Stainless steel

Stainless steel

Stainless steel

Stainless steel

Stainless steel

Stainless steel

Stainless steel

Stainless steel

Stainless steel

Stainless steel

DIN 1693 GGG 40

BS 970 431 S29

BS 1449 304 S11

BS 6105 CI A2-70

BS 1449 304 S16

BS 1449 304 S16

BS 1449 304 S11

BS 1449 304 S16

BS 1449 304 S16

PN16

16 bar g @ 100°C

250°C @ 13 bar g

-10°C

14 bar g

240°C @ 13 bar g

0°C

4.5 bar

10 bar

14 bar

Designed for a maximum cold hydraulic test pressure of 24 bar g

PMA Maximum allowable pressure

TMA Maximum allowable temperature

Minimum allowable temperature

PMO

Maximum operating pressure

for saturated steam service

TMO Maximum operating temperature

Minimum operating temperature

Maximum

PMX differential

IFT14-4.5

IFT14-10

IFT14-14

pressure

27

Blanking plug

(not shown)

Local regulations may restrict the use of this product to below the conditions quoted.

In the interests of development and improvement of the product, we reserve the right to change the specification without notice.

© Copyright 2007

Stainless steel

reinforced exfoliated graphite

Steel

* Note: Items 5, 6, 7, 10, 11 and 18 are shown more clearly overleaf.
