Materials
No.
Part
Material
1
Actuator case
Glass filled Polymer
2
Handwheel
POM
C
B
3
Cable inlet
4
Pillar
5
Linkage
6
Mounting flange
PA
Steel BZP passivated
3
1
2
4.3.32
4
5
6
Dimensions / weights (approximately) in mm and kg
Actuator range
EL7211A-SE
EL7212A-SE
EL7213A-SE
A
B
C*
471
100
140
471
100
200
446
100
200
Weight
3.0
3.0
3.0
EL7200 series selection guide
Ordering a control valve
Type
Series
Actuator thrust
Actuator travel
Voltage
Control mode
Failure mode
EL =
7 =
2 =
1 =
1 =
2 =
3 =
A =
SE =
Electric
EL
7000 series
7
1.0kN
2
2
0
1
230 Vac
115 Vac
1
24Vac
0/4 - 20 mA + 0/2 - 10 Vdc + VMD
A
Spring extend
SE
How to order
Example: 1 off EL7211A-SE 230 Vac electric actuator with spring extend.
Spares
Spare parts are available as indicated. No other parts are available as spares.
Linkage (DN15 to DN50)
5
Mounting flange (DN15 to DN50)
6
How to order spares
Always order spares by using the description given above and state exactly
which product they are for.
Example: 1 - Mounting flange for a EL7211A-SE 230 Vac electric actuator.
EL7211A-SE
Control valves
Electric actuators
* Actuator cover removal distance
