Solenoid Valves

for use with Piston Actuated Valves

Cert. No. LRQ 0963008

Description

A 3-port two way electropneumatic pilot solenoid valve that can be

directly mounted (banjo connection) to the PF51G and PF61G-NC,

NO and BD series piston actuated valves.

Suitable for air or water operating media. The valve is supplied with

a DIN connector and fitted with manual override as standard.

Available types

Model

Actuator

DM11

45 mm

DM12

45 mm

DM13

45 mm

DM14

45 mm

DM21

63 mm

DM22

63 mm

DM23

63 mm

DM24

63 mm

DM31

90 mm

DM32

90 mm

DM33

90 mm

DM34

90 mm

Voltage / Frequency

230/50 or 240/60 Vac

110/50 or 120/60 Vac

24/50 or 24/60 Vac

24 Vdc

230/50 or 240/60 Vac

110/50 or 120/60 Vac

24/50 or 24/60 Vac

24 Vdc

230/50 or 240/60 Vac

110/50 or 120/60 Vac

24/50 or 24/60 Vac

24 Vdc

Connection

1

/

8

" BSP

1

/

8

" BSP

1

/

8

" BSP

1

/

8

" BSP

1⁄4" BSP

1⁄4" BSP

1⁄4" BSP

1⁄4" BSP

1⁄4" BSP

1⁄4" BSP

1⁄4" BSP

1⁄4" BSP

Technical details

Mounting

Manual override

DIN connector

Pilot media

connection

Coil

consumption

Type B

Type B

Type A

DM11 to DM14

DM21 to DM24

DM31 to DM34

DM11, DM12,

DM13 and DM14

DM21, DM22,

DM23, and DM24

DM31, DM32,

DM33 and DM34

Banjo connection

Fitted as standard

DM11, DM12, DM13 and DM14

DM21, DM22, DM23 and DM24

DM31, DM32, DM33 and DM34

Push in type to suit 6 mm dia.

nylon or copper tube

ac 10 VA (holding)

sc 16 VA (maximum)

dc 7 Watts

ac 10 VA (holding)

ac 16 VA (maximum)

dc 7 Watts

ac 18 VA (holding)

ac 36 VA (maximum)

dc 14 Watts

60°C

-10°C

IP65 (with connector)

0bargmin.to10bargmax.

Material

ELNP Niploy coated brass

FKM

Dimensions / weights (approximate) in mm and kg

Type

DM11, DM12, DM13 and DM14

DM21, DM22, DM23 and DM24

DM31, DM32, DM33 and DM34

DIN

connector

A

B

C

31

77

27

35

78

27

35

95

27

Earth

terminal

C

A

Weight

0.27

0.27

0.38

Limiting conditions

Maximum media temperature

Minimum media temperature

Protection class

Operating pressure

Materials

Part

Body

Seal

Spares parts

B

No spares are available for this product.

Installation

The valve can be directly mounted (banjo connection) onto the actuator.

How to order

Example: 1 off Spirax Sarco DM21 solenoid valve 240 Vac.
