Boiler house

Bottom blowdown systems

BBV83

Pressure / temperature limits - EN 1092

������

A

S

R

������

������

������

������

��

������

The product must not be used in this region.

An extended cover is required for use in this region.

High temperature packing required for use in this region.

Notes:

1. Where the process fluid temperature is sub-zero and the ambient temperature is below +5 °C, the external moving parts of the valve

and actuator must be heat traced to maintain normal operation.

2. When selecting a valve with a bellows scaled bonnet, the pressure / temperature limits of the bellows must be read in conjunction with

the valve pressure / temperature limits shown in table below.

Steam

saturat

curve

ion

S

R

��

����

����

����

����

������

Pressure bar g

A-R-R

PN100

A-S-S

PN63

Body design conditions

PMA Maximum allowable pressure

and

PMO Maximum operating pressure

TMA Maximum allowable temperature

Minimum allowable temperature

TMO Maximum operating temperature

Minimum operating temperature

Standard packing PTFE chevron (P)

High temperature packing (H)

PN100

100 bar g @ 250 °C

490 °C @ 68 bar g

-29 °C

250 °C @ 100 bar g

490 °C @ 68 bar g

-29 °C

156 bar g

PN63

63 bar g @ 250 °C

490 °C @ 40.9 bar g

-29 °C

250 °C @ 63 bar g

490 °C @ 40,9 bar g

-29 °C

156 bar g

Design for a maximum cold hydraulic test pressure of:

Body design conditions

PMA Maximum allowable pressure

and

PMO Maximum operating pressure

TMA Maximum allowable temperature

Minimum allowable temperature

TMO Maximum operating temperature

Minimum operating temperature

Standard packing PTFE chevron (P)

High temperature packing (H)

Design for a maximum cold hydraulic test pressure of:
