Pipeline ancillaries

Strainers and filters

7.7.77

Capacity correction factors for air pressure

Air pressure

bar g

1

2

3

4

5

6

7

8

Correction factor

Air pressure

Correction factor

0.25

0.375

0.5

0.625

0.75

9

10

11

12

13

1.25

1.375

1.5

1.625

1.75

0.875

1.0

1.125

bar g

14

15

16

1.875

2.0

2.125

CSF16 and CSF16T air sizing:

Select an air filter for a flowrate of 500 m3/h with air pressure at 4 bar g.

Step 1: Divide the flowrate required by the capacity correction factor for the operating air pressure. In this case, 500 m3/h is divided

by 0.625 for an equivalent 800 m3/h flow.

Step 2: Using the look up tables below select a filter to pass the equivalent flow in this case a 2"H CSF16 or CSF16T with a

maximum flowrate or 1080 m3/h

CSF16 and CSF16T air sizing table

Please note that the flowrates displayed on the CSF16 and CSF16T air sizing table are based on an air pressure of 7 bar g.

Size of unit

Maximum flowrate m

3

/ h

Size of unit

Maximum flowrate m

3

/h

DN8

DN10

DN15

DN20

DN25

DN32

DN40

DN50L

DN50H

1⁄4"

"

1⁄2"

3⁄4"

1"

11⁄4"

11⁄2"

2"L

2"H

60

90

DN65

DN80L

21⁄2"

3"L

1440

1920

120

180

DN80H

DN100L

3"H

4"L

2880

4320

270

360

DN100H DN150L

4"H

6"L

5760

7680

480

720

DN150H DN200L

6"H

8"L

11520

15360

1 080

DN200H

8"H

19200

Safety information, installation and maintenance

For full details see the Installation and Maintenance Instructions (IM-P185-02) which is supplied with the product.

How to order

The following information must be specified when ordering a Spirax Sarco CSF filter:

Compressed air flowrate

Compressed air flowrate

Allowable pressure drop bar

Housing material

Size

Pipe connections

Housing seal /element seal material

m3/h

bar

(0.07 bar maximum recommended)

1.4301 or 1.4404

DN or NPS (")

EN, ASME, BSP or NPT

Note: For DN50 and DN80 high capacity version denoted by 'H' and low capacity by 'L'. For a 1.4404 housing version, the suffix 'T'

must be added to the nomenclature e.g. CSF16T.

Supply

The CSF16 and CSF16T are supplied in two parts:

1. The filter housing head and bowl with housing seal packed in one carton.

2. The filter element complete with filter element seals (2 off).

Note: The job of the filter is to remove (and retain) unwanted contamination. In time, the filter element will become saturated.

To ensure a minimum downtime, we recommend that a spare filter element set is ordered at the same time as the CSF16 and CSF16T

filter housing.

Example:

1 off Spirax Sarco DN20 CSF16 to pass compressed air at 4 bar g. Housing to be 1.4301 having NPT connections element with EPM

body seal.

1 off CSF16-A borosilicate depth filter element.
