Kv values

Size

Perforations

0.8, 1.6 and 3 mm

Mesh 40 and 100

Mesh 200

For conversion:

" 1⁄2" 3⁄4" 1" 11⁄4"11⁄2" 2"

2.6 3 6.2 11.3 26 41 68

21⁄2"

98

Spare parts

The spare parts available are shown in solid outline. Parts drawn

in broken line are not supplied as spares.

Available spares

Strainer screen.

4

(state material, size of perforation or mesh and size of strainer)

Cap gasket (packet of 3)

3

How to order spares

Always order spares by using the description given in the column

headed 'Available spares' and state the size and type of strainer and

perforations or mesh required.

Example: 1 - Stainless steel strainer screen having 0.8 mm

perforations for a 3⁄4" Spirax Sarco Fig 12 strainer.

Bronze body

1⁄2"

72

3⁄4"

82

1"

11⁄4"

11⁄2"

2"

21⁄2"

104

138

150

178

207

D

B

TI-P164-02 ST Issue 8

Fig 12 Brass and Bronze Strainers

2.6 3

6.2 11.3

26 41

21 33

Cv (US) = Kv x 1.156

2.6 3

Cv (UK) = Kv x 0.963

Dimensions/weights (approximate) in mm and kg

Brass body

54

85

30A/F

27

0.55

64

110

36A/F

43

0.70

72

130

46A/F

73

1.00

100

170

52A/F

135

1.60

110

190

60A/F

164

2.10

133

212

79A/F

251

4.80

152

240

98A/F

327

7.70

Size

A

"

69

50

80

24A/F

27

0.45

B

C

D

Weight

A

Fig 12

Sizes 1⁄2" to 1"

3

4

6.2 9.3

Screening

area cm2

Withdrawal distance

Safety information, installation and maintenance

For full details see the Installation and Maintenance Instructions

(IM-S60-17) supplied with the product.

Installation note:

Suitable isolation valves must be installed to allow for safe

maintenance and trap replacement. We also recommend that a Spirax

Sarco DV depressurisation type valve (see the product specific TI

literature for further details) be installed to ensure that any pressure

is isolated and safely vented to atmospheric pressure before

attempting to maintain the strainer.

Maintenance note:

Maintenance can be completed with the strainer in the pipeline, once

the safety procedures have been observed. It is recommended that

a new gasket is used whenever maintenance is undertaken.

Disposal

The product is recyclable. No ecological hazard is anticipated with

disposal of this product, providing due care is taken.

How to order

Example: 1 off Spirax Sarco 11⁄2" Fig 12 bronze strainer with

screwed BSP connections and stainless steel screen having

0.8 mm perforations.

2

Pipeline ancillaries

Strainers and filters

C

2

7.7.4

68

55 78

98

Fig 12

Sizes "

and 11⁄4" to 21⁄2"
