Size
1⁄2"
3⁄4"
1"
Example: 1 off Spirax Sarco DCV41 austenitic stainless steel
bodied disc check valve having 1⁄2" screwed BSP connections
supplied fitted with a Viton soft seat and certification to
EN 10204 3.1 for the body.
For full details see the Installation and Maintenance Instructions
(IM-P601-19) supplied with the product.
The DCV41 disc check valve must be fitted in accordance with the
direction of flow arrow indicating correct fluid flow direction. When
fitted with a spring, they can be installed in any plane. When
supplied without spring, they must be fitted in a vertical flow line
with the flow from bottom-to-top.
Note: Disc check valves are non-maintainable (no spares are
available). Disc check valves are not suitable for use where
heavily pulsating flow exists, such as close to a compressor.
Various options are denoted by a marking on the valve body:-
Kv
4.4
7.5
12
For conversion:
Cv (UK) = Kv x 0.963
Cv (US) = Kv x 1.156
Differential pressures with zero flow for standard and high
temperature springs.
Flow direction
All sizes
20
Where lower opening pressures are required, valves without
springs can be installed in vertical pipes with bottom-to-top flow.
25 22.5
Without spring and flow direction
Size
mbar
1⁄2"
3.0
3⁄4"
1"
2.5
4.0
'N'
- High temperature spring
'W'
- Without spring
'WV' - Without spring
'WE' - Without spring
'H'
- Heavy duty spring
'HV' - Heavy duty spring
'HE' - Heavy duty spring
'V'
- Standard spring
'E'
- Standard spring
- Standard metal seat
- Standard metal seat
- Viton seat
- EPDM seat
- Standard metal seat
- Viton seat
- EPDM seat
- Viton seat
Heavy duty springs approximately 700 mbar
- EPDM seat
No identification indicates a standard spring with a metal disc.
If a product which contains a Viton component has been subjected
to a temperature approaching 315 °C or higher, then it may have
decomposed and formed hydrofluoric acid. Avoid skin contact and
inhalation of any fumes as the acid will cause deep skin burns and
damage to the respiratory system. Viton must be disposed of in a
recognised manner as stated in the Installation and Maintenance
Instructions (IM-P601-19). No other ecological hazard is
anticipated with the disposal of this product providing due care is
taken.
Pressure loss in bar
Pressure loss diagram with open valve at 20 °C. The values
indicated are applicable to spring loaded valves with horizontal
flow. With vertical flow, insignificant deviations occur only within
the range of partial opening.
The curves given in the chart are valid for water at 20 °C. To
determine the pressure for other fluids the equivalent water volume
flowrate must be calculated and used in the graph.
Vw=
1000
xV
Vw
Where:
V
= Equivalent water volume flow in l/s or m3 / h
= Density of fluid kg / m3
= Volume of fluid l/s or m3/h
Pressure loss information for steam, compressed air and gases is
available from Spirax Sarco.
