Pipeline ancillaries
HVB3aslltvoaplveaslve
D
7.4.141
Dimensions/weights (approximate) in mm and kg
Flanged ASME 150
Size
A
B
C
D
E
F Weight
Flanged ASME 300
Size
A
B
C
D
E
F Weight
DN25
127
62
DN32
140
65
DN40
165
70
DN50
178
75
DN65
190
79
DN80
203
91
DN100 229
98
DN150 267
130
162
108
101
182
118
106
186
127
118
186
152
123
278
178
144
417
191
157
517
229
172
700
279
205
19
2.9
25
3.8
30
5.4
37
7.9
50
12.0
57
15.8
75
24.8
100
43.8
DN25
165
DN32
178
DN40
190
DN50
216
DN65
241
DN80
283
DN100 305
DN150 403
62
162
124
101
65
182
134
106
70
186
156
118
75
186
165
123
79
278
190
144
91
417
210
157
98
517
254
172
130
700
318
205
19
4.5
25
5.7
30
8.2
37
10.3
50
16.0
57
22.3
75
36.1
100
66.6
B
C
B
C
E
E
ØD
ØF
Ø
DN25 to DN50
A
A
ØF
DN65 to DN150
Kv values
DN
Kv
For conversion:
25
32
40
50
65
80
100
150
30
40
81
103
197
248
581
735
Cv (UK) = Kv x 0.963
Cv (US) = Kv x 1.156
Operating torques (Nm)
DN
25
32
40
50
65
80
100
150
Nm
20
25
35
60
100
120
170
400
Note: The torque figures shown are for a valve that is frequently operated at the maximum operating pressure. Valves that are subject to
long static periods, may require a greater break-out torque.
Safety information, installation and maintenance
For full details see the Installation and Maintenance Instructions supplied with the product.
Welding
Only the models that have connections designed for welding (SW, BW, Imperial Tube connections) should be welded. Valves with flanged
connections must not be welded to avoid damages to the valve and/or injury to personnel.
How to order
Specify
Body material
2 = Zinc plated carbon steel
3 = Stainless steel
Example: 1 off Spirax Sarco DN50 M40Hi2 ISO ball valve having flanged ASME 150 connections.
Optional extras:
-
Self-venting ball.
-
Extended stems to allow full insulation: 50 mm (2") for DN25 to DN50 sizes and 100 mm (4") for DN25 to DN150 sizes.
-
Lockable handle.
-
100 mm extended stem with lockable handle.
Page 4 of 6
TI-P133-87 ST Issue 2
M40Hi ISO Reduced Bore Ball Valve DN25 to DN150 Flanged ASME 150 and ASME 300
