Pipeline ancillaries

HVB3aslltvoaplveaslve

Local regulations may restrict the use of this product to below the conditions quoted.

In the interests of development and improvement of the product, we reserve the right to change the specification without notice.

© Copyright 2012

TI-P133-08

ST Issue 13

M10V

Ball Valve

DN1⁄4" to 21⁄2"

Description

Pressure / temperature limits

A

����

��

��

A-B

A-C

A-D

A-E

A-F

Note 1:

Note 2:

The M10V three-piece body ball valve has been designed for use

as an isolating valve, not a control valve, and can be serviced

without removal from the pipeline (screwed and welded versions

only). It can be used with the majority of industrial fluids.

Available types

������

������

������

������

����

M10V2__

M10V3_ _

M10V4__

Zinc plated carbon steel body, PTFE seats.

Stainless steel body, PTFE seats.

Complete stainless steel, PTFE seats.

C

E

D

Steam

saturati

curve

on

F

E

D

C

B

Note: The nomenclature will be followed with either FB (full bore) or

��

����

����

����

����

����

����

����

Pressure bar g

RB (reduced bore).

Standards

This product fully complies with the requirements of the

European Pressure Equipment Directive 97/23/EC and carries

the mark when so required.

This product is available with certification to EN 10204 3.1.

Note: All certification / inspection requirements must be stated

at the time of order placement.

Sizes and pipe connections

Full bore

1⁄4", ", 1⁄2", 3⁄4", 1", 11⁄4", 11⁄2" and 2"

Screwed and welded

BSP, BSPT, API / NPT, BW, SW

Reduced bore

1⁄4", ", 1⁄2", 3⁄4", 1", 11⁄4", 11⁄2", 2" and 21⁄2"

Screwed and welded

BSP, BSPT, API / NPT, BW, SW

Technical data

Flow characteristic

Port

Leakage test procedure to ISO 5208 (Rate A) / EN 12266-1 (Rate A)

Antistatic device

Complies with ISO 7121 and BS 5351

The product must not be used in this region.

Screwed, SW and BW 1⁄4" - 11⁄2" FB, RB and 2" RB.

Certification

Screwed, SW and BW 2" FB and 21⁄2" RB only.

Flanged ASME 300.

Flanged EN 1092 PN40.

Flanged ASME 150.

Flanged

On the 2" FB and 21⁄2" RB a PTFE gasket is fitted between

the body and cap.

The flange standard may restrict the maximum operating

pressure. Please check with Spirax Sarco.

DN15 to DN50

ASME Class 150,

ASME Class 300,

and EN 1092 PN40.

DN15 to DN65

ASME Class 150,

ASME Class 300,

and EN 1092 PN40.

Body design conditions

PMA Maximum allowable pressure

TMA Maximum allowable temperature

Minimum allowable temperature

PMO

Maximum operating pressure

for saturated steam service

TMO Maximum operating temperature

Minimum operating temperature

PN100

70 bar g @ 40°C

230°C @ 0 bar g

-29°C

10 bar g

230°C @ 0 bar g

Flanged

Modified linear

Full and reduced port versions

-29°C

Note: For lower operating temperatures consult Spirax Sarco

PMX Maximum differential pressure is limited to the PMO

Designed for a maximum cold hydraulic test pressure of 105 bar g

Page 1 of 4

7.4.2

T

e

m

p

e

r

a

t

u

r

e

°

C
