Thermometer valve with flow check valve TKS - DN 32

1 x PAW flange (without nut) 1" (DN 25) / 1

1⁄4" (DN 32)

1 x internal thread 1" (DN 25) / 11⁄4" (DN 32)

1 x sleeve (on the side) 1⁄2", for overflow valve or

immersion sleeve/sensor connection

1 x self-sealing blind plug 1⁄2"

diameter thermometer = 50 mm

dial thermometer with red scale in the handle,

handle can be pulled off with thermometer,

check valve 200 mm wc, can be opened

int.: 1

1⁄4"

104 mm

96561

Ball valve - DN 25

1 x external thread

1 x nut G = 1"

key actuated, ideal to shut off armoured hoses as it is

flat-sealing

ext.: 1"

50 mm

905003

Elbow ball valve DN 25

1 x 1" external thread

1 x nut G = 1"

key actuated, ideal to shut off armoured hoses as it is

flat-sealing

ext.: 1"

87 mm

905002

Handle extension for ball valve - DN 40/50

Function: for thick insulation of the ball valve

Material: Brass, chromed

Can be replaced under pressure when the ball valve is

closed.

available for: MK, PK, TK, KMM, KMV.

nominal diameter: DN 20, 25, 32, 40, 50

Please state the type of ball valve and the nominal

diameter when ordering!

95 mm

2165

Full port ball valve KMA - DN 15

1 x

1⁄2" external thread

1 x

1⁄2" internal thread

int.:

1⁄2"

ext.: 1⁄2"

48,5 mm

2218

Full port ball valve KMA - DN 20

1 x

3⁄4" external thread

1 x

3⁄4" internal thread

int.:

3⁄4"

ext.:

3⁄4"

64 mm

2219

Full port ball valve KMA - DN 25

1 x 1" external thread

1 x 1" internal thread

Material: Brass, nickel-plated,

Max. operating temperature = 100 °C

with red butterfly handle

int.: 1"

ext.: 1"

66 mm

2220

Connection

Thermometer valve with flow check valve TKS - DN 25

int.: 1"

Length

81 mm

Item no.

96551

200
