Product range HeatBloC®

Heating circuits DN 40/50

All HeatBloC®s offer

the following advantages:

D

N

4

0

/

D

N

5

0

124

Preassembled group of fittings for heating circuits

High

flexibility during assembly

modules can be used in nearly any combination

Ball valve with full port, gaskets of the spindle can be replaced

during operation

Connections

Flange connection DN 40/PN6 resp. DN 50/PN6 as slip-on

flange and 11⁄2‘‘

/ 2‘‘ internal thread

incl. gaskets and screws, for installation on PAW modular distribution

manifolds

With PAW mounting equipment the heating circuit can be installed on

wall brackets.

Hand lever at the ball valve

easy handling from the front, even when the insulation is closed,

visible closing position

EnEV-compliant functional insulation

made of durable elastic EPP, complete insulation of valves and

fittings,

ventilation opening to cool the pump.

Free access to the pump head

Check valve in the return pipe

can be opened, 200 mm wc, spring-loaded, and thus also suited for

horizontal and overhead installation

Flow on the right = standard

The HeatBloC®s can be delivered with

flow on the left against additional

charge.

Flow and return line can be changed on site

also for heating circuits with mixing valve

Fill and drain valve

for

flushing, filling and draining, integrated in the ball valve

Full metal thermometer

can be pulled off, with immersion sleeve, integrated in the ball valve

PAW heating pumps with high-e

fficiency technology

(ECM technology)

fitted with cable, already installed, integrated in the insulation, pressure

tested, serial number, perfectly designed system, pump characteristics,

EuP/ErP READY

Pump can be isolated

so that it can be replaced without draining

At the end of the chapter, you will find the complete mounting

equipment for the modular system DN 40 / 50.
