Atlas Concorde - General Book 2025

Atlas Concorde

Catalog 2025

Technical Specifications

Destinations of use

Color-Shading

HEAVY

TRAFFIC

HEAVY COMMERCIAL

Malls, airports, places of worship, schools,

museums, squares, hospitals, hotels - foyers,

undergrounds, train stations, etc.

COMMERCIALI PESANTI

Mall, aeroporti, luoghi di culto, scuole, musei,

piazze, ospedali, hotel - hall di ingresso,

metropolitane, stazioni ferroviarie, ecc...

Outdoor Sensitech 20 mm

Grip / Grip Sensitech 9 mm

Textured / Roccia 9 mm

INTENDED USES FOR OUTDOORS

INDUSTRIAL AND/OR COMMERCIAL

AREAS FOR VEHICLES

Squares, public car parks, filling stations,

paving for forklift trucks, pallet jacks, trailer

trucks, buses, industrial platforms, etc.

INSTALLATION METHOD

1. LAYING WITH ADHESIVE using the

"double buttering" method. Choose porcelain

tile with a thickness greater than or equal to

20mm with anti-slip finish

(2)

AREE INDUSTRIALI E/O COMMERCIALI

CARRABILI

Piazze, parcheggi pubblici, stazioni di

rifornimento, pavimentazioni con transito di

carrelli elevatori, transpallet, autoarticolati,

autobus, piattaforme industriali, ecc...

TIPO DI POSA

1. POSA CON ADESIVI con il metodo

della "doppia spalmatura". Utilizzare gres

porcelanato a spessore superiore o uguale a

20mm con finitura anti-scivolo

(2)

MEDIUM

TRAFFIC

MEDIUM COMMERCIAL*

Restaurants, offices, shops, public restrooms, public offices,

hotels except for foyers, business lounges, mandatory

passageways and areas subject to the transit of trolleys with

hard wheels or highly concentrated loads.

COMMERCIALI MEDI*

Ristoranti, uffici, negozi, bagni pubblici, uffici pubblici,

hotel - ad esclusione delle hall di ingresso, business lounge,

di passaggi obbligati e zone soggetto a transito di carrelli con

ruote dure ovvero elevati carichi concentrati.

LIGHT

TRAFFIC

RESIDENTIAL

Bedrooms, living rooms, studies, private kitchens, private

bathrooms, etc.

RESIDENZIALI

Camere da letto, soggiorni, studi, cucine private,

bagni privati...

Silk6-9mm

Polished 6 - 9 mm

Velvet Velvetech 9 mm

(1)

POOL EDGES

INSTALLATION METHOD

LAYING WITH ADHESIVE using the "double

buttering" method. Choose porcelain tiles

with anti-slip finish

(2)

BORDI PISCINA

TIPO DI POSA

POSA CON ADESIVI con il metodo

della "doppia spalmatura". Utilizzare gres

porcellanato con finitura anti-scivolo

(2)

The V-Shade classification indicates the chromatic and/or surface variation among tiles of the same collection.

La classificazione VShade indica variazione cromatica e/o superficiale tra le piastrelle di una stessa collezione.

La classification VShade indique le variation chromatique et/ou superficielle entre des dalles d’une même collection.

Die Klassifizierung V-Shade gibt das Niveau des Farbverlaufs des Produktes oder die Abweichung des Farbtons und/oder Oberfläche unter den Fliesen der gleichen Kollektion an.

La clasificación V-Shade indica el variación cromática y/o superficial que existe entre las baldosas de una misma colección.

Классификация V-Shade указывает на уровень цветовой или фактурной неоднородности плиток, т.е. на отличия по цвету или по фактуре между плитками одной коллекции.

Matte Sensitech 9 mm

Matte 9 mm

Matte 6 mm

RESIDENTIAL AREAS FOR VEHICLES

Outdoor courtyards, private homes,

apartment complex parking lots (garages),

etc. Pavements used only by cars.

INSTALLATION METHOD

LAYING WITH ADHESIVE using the

"double buttering" method.

Choose porcelain tiles with anti-slip finish

(2)

AREE RESIDENZIALI CARRABILI

Cortili esterni abitazioni private, parcheggi

condominiali (garage interni), ecc...

Pavimentazioni a transito esclusivo

di autovetture.

TIPO DI POSA

POSA CON ADESIVI con il metodo

della "doppia spalmatura". Utilizzare gres

porcellanato con finitura anti-scivolo

(2)

Uniform appearance

Aspetto uniforme

Aspect uniforme

V1

Gleichmäßiges Erscheinungsbild

V2

Slight variation

Variazione minima

Variation minimale

Leichte Abweichung

Variación mínima

Минимальная Неоднородность

V3

Moderate variation

Variazione moderata

Variation Modérée

Mäßige Abweichung

Variación moderada

Умеренная Неоднородность

V4

Substantial variation

Variazione sostanziale

Variation substantielle

Grundlegende Abweichung

Variación sustancial

Значительная Неоднородность

Aspecto uniforme

Однородный вид

Collection

Colour

Colour-shading

Collection

Colour

Colour-shading

AREAS FOR PEDESTRIANS ONLY

Patios, gardens and walkways, terraces,

balconies, urban pedestrian areas, etc.

INSTALLATION METHOD

1. RAISED INSTALLATION AND "DRY"

L AYING (on grass, sand and gravel).

Choose porcelain tile with a thickness

greater than or equal to 20mm

with anti-slip finish

(2)

2. LAYING WITH ADHESIVE using the

"double buttering" method.

Choose porcelain tiles with anti-slip finish

(2)

AREE SOLO PEDONABILI

Patii, giardini e camminamenti, terrazze,

balconi, aree urbane pedonali, ecc...

TIPO DI POSA

1. POSA SOPRAELEVATA E A "SECCO"

(su erba, sabbia e ghiaia). Utilizzare gres

porcelanato a spessore superiore o uguale

a 20mm con finitura anti-scivolo

(2)

2. POSA CON ADESIVI con il metodo

della "doppia spalmatura". Utilizzare gres

porcelanato con finitura anti-scivolo

(2)

3D WALL CARVE

3D WALL DESIGN

3D WALL PLASTER

APLOMB

Wall tiles

Porcelain

V3 Porcelain tiles

MARVEL

DIVA

DREAM

GALA

GEMS

Porcelain

Wall tiles

Porcelain

& Wall tiles

AXI

BOOST

BRAVE

ENTICE

ETIC

tiles

Golden Oak

tiles

& Wall tiles

tiles

& Wall tiles

tiles

& Wall tiles

tiles

& Wall tiles

tiles

& Wall tiles

tiles

V2 Wall

tiles

MARVEL

MERAVIGLIA

BALANCE

COLOR

EXPRESSION

ICOR

MINERAL

MIX

NATURAL

NATURAL PRO

PRO

STONE

MARVEL

ONYX

SHINE

STONE

Porcelain

& Wall tiles

Porcelain tiles

Calacatta Delicato

Statuario Supremo

Calacatta Apuano

Calacatta Perla

Fior di Bosco

Calacatta Prestigio

Calacatta Imperiale

Calacatta Sublime

Grey Cloud

* Polished and silk finishes are recommended for low-stress residential or commercial floors where anti-slip performance is not required. The surface’s shine and superior ease of cleaning are the result of in-depth studies and extensive technical research aimed

at ensuring its durability over time. If the product is in direct contact with the outside, use moisture and dirt absorption devices to prevent scratches. Under no circumstances does Atlas Concorde accept responsibility for any use of the product other than as

recommended above. - Le finiture lappata e silk sono indicate per pavimenti residenziali o commerciali poco sollecitati, laddove non siano richieste prestazioni antiscivolo. La lucentezza e l’elevata facilità di pulizia della superficie sono frutto di studi approfonditi

e accurate ricerche tecniche volte a garantirne la persistenza nel tempo. Se il prodotto è a diretto contatto con l’esterno, prevedere dei dispositivi di assorbimento dell’umidità e dello sporco per prevenire la formazione di graffi. Atlas Concorde non si assume in

nessun caso la responsabilità per un uso del prodotto diverso da quanto consigliato sopra.- Les finitions rodée et soyeuse conviennent aux sols résidentiels ou commerciaux à faibles contraintes, où la performance antidérapante n'est pas requise. La brillance et

la grande facilité de nettoyage de la surface sont le résultat d'

études approfondies et de recherches techniques précises visant à assurer sa persistance dans le temps. Si le produit est en contact direct avec l'extérieur, prévoyez des dispositifs d'absorption de

l'humidité et de la saleté pour éviter la formation de rayures. Atlas Concorde n'accepte aucune responsabilité pour toute utilisation du produit autre que celle recommandée ci-dessus. - Die Oberflächenversionen Geläppt und Silk eignen sich für Bodenbeläge

in Wohnbereichen bzw. in gering beanspruchten Gewerberäumen, wenn keine Rutschfestigkeit erforderlich ist. Der Glanz und die einfache Reinigung der Oberfläche sind das Resultat eingehender technischer Studien, mit denen die langfristige Beständigkeit

sichergestellt wurde. Kommt das Produkt direkt mit der externen Umgebung in Kontakt, so sind Feuchtigkeit und Schmutz mit geeigneten Mitteln aufzunehmen, um Kratzer zu vermeiden. Atlas Concorde haftet keinesfalls für eine nicht den vorstehenden

Empfehlungen entsprechende Verwendung des Produkts. - Los acabados lapeados y silk son adecuados para pavimentos residenciales y comerciales con poco tráfico, donde no se requiere un efecto antideslizante. El brillo y la gran facilidad de limpieza de la

superficie son el resultado de profundos estudios e investigaciones t

écnicas precisas para asegurar su persistencia en el tiempo. Si el producto está en contacto directo con el exterior, proporcionar dispositivos de absorción de humedad y suciedad para evitar

arañazos. Atlas Concorde no asume responsabilidad alguna por cualquier uso del producto distinto del recomendado anteriormente. - Лаппатированная поверхность и поверхность Silk рекомендованы для полов жилых и коммерческих помещений с

невысокой интенсивностью эксплуатации, в которых от покрыти

й не требуется характеристик сопротивления скольжению. Блеск и легкая очищаемость являются результатом глубоких исследований, направленных на создание долговечного материала.

Если плитка находится в непосредственном контакте с наружной средой, необходимо предусмотреть устройства поглощения влаги и грязи во избежание образования царапин. Atlas Concorde не несет ответственности за использование изделий с

нарушением вышеприведенных рекомендаций.

(2)

For the properties of slip resistance required in the aforementioned uses it is always necessary to comply with the local laws, regulations and uses, referring to the technical sheets of the selected products. - Per le proprietà di resistenza allo scivolamento

richieste nelle destinazioni d’uso sopra itate occorre sempre attenersi alle normative, leggi ed usi locali facendo riferimento alle schede tecniche dei prodotti selezionati. - Pour les propriétés de résistance à la glissade exigées par les destinations d'usage

susmentionnées, il faut toujours respecter les normes, lois et réglementations locales en se référant aux fiches techniques des produits sélectionnés. - Für die von den obigen Zweckbestimmungen verlangte Rutschfestigkeit sind stets die örtlich geltenden

Vorschriften, Gesetze und Gebräuche zu beachten. Siehe hierzu die technischen Datenblätter der gewählten Produkte. - Para las propiedades de resistencia al deslizamiento requeridas según los usos previstos antes indicados, es taxativo atenerse a las

normativas, leyes y usos locales siempre consultando las fichas técnicas de los productos seleccionados. - Характеристики сопротивления скольжению при использовании плиток для вышеописанных назначений выбирают согласно местным законам,

стандартам и правилам по листу технических характеристик выбранных изделий.

Rovere

V3 Porcelain tiles

V2 Wall tiles

V3 Porcelain tiles

V2 Wall tiles

V2 Natural selection

V3 Forest selection

MARVEL

TRAVERTINE

MARVEL X

NORDE

PRISM

ETIC PRO

EXENCE

HEARTWOOD

LIMS

LOG

LOG CANSEI

Porcelain & Wall tiles

PRECAUTIONS – VELVET IS A DELICATE SURFACE

(1)

The Velvet finish is a delicate surface that requires care. To preserve its beauty and ensure proper use, please refer to our instructions on page 378.

La finitura Velvet è una superficie delicata che merita attenzione. Per mantenerne integra la bellezza e garantire un uso adeguato, consultare le nostre istruzioni pag 378.

402

403

Destinations of use

Recommended products by intended use

Color-Shading

V1

V2

V3

V4

INDEX

PRODUCT

FINDER

SURFACE

RANGE

COMPANY

COLLECTIONS

LARGE SIZES

SLABS FOR

COUNTERTOPS

& FURNITURE

BATHROOM

FURNITURE

& TABLES

FACADES

TECHNICAL

SPECIFICATIONS
