PRATICITÀ. Nella parte superiore sono presenti 2 coperchi che

permettono l’accesso al serbatoio pellet e alla parte superiore

della caldaia per le operazioni di pulizia.

MANUTENZIONE. le procedure di pulizia dell’interno della cal-

daia sono rese molto semplici e veloci grazie a:

- cassetto cenere principale a cui si accede aprendo la porta.

- cassetto cenere secondario estraibile, protetto da un carter

a pressione posto frontalmente nella parte inferiore della ter-

mostufa, raccoglie i residui della combustione del 2°, 3° e 4°

giro di fumi, il tutto senza dover smontare parti complesse della

termostufa.

- coperchio superiore che da accesso agli scambiatori di tutti i

giri di fumi. in dotazione lo scovolo di pulizia per tutti gli scam-

biatori interni.

anche la particolare posizione del circolatore, posto nella parte

posteriore, permette il controllo e lo sblocco dello stesso senza

dover spostare o smontare nessuna parte della termostufa.

MATERIALI e SPESSORI. la robusta struttura in acciaio della

caldaia garantisce una lunga durata nel tempo. come richiede

la normativa, gli spessori delle lamiere a contatto con fuoco e

acqua sono di 5mm e quelle a contatto solo con acqua di 4 mm.

FUNZIONAMENTO. Grazie alle 7 potenze di combustione e una

di mantenimento (modulazione), si riesce sempre a trovare il

giusto comfort climatico. Sfruttando i 4 giri reali dei fumi si ot-

tiene un alto rendimento fino al 94% e una bassa temperatura

dei fumi.

PRODUZIONE ACQUA CALDA SANITARIA (a richiesta cod. 0153

SiST/P). Specifico kit per la produzione di acqua calda sanitaria

composto da scambiatore a piastre, valvola deviatrice e flusso-

stato; in grado di produrre alla potenza massima un flusso con-

tinuo di 700 litri/ora con salto termico (∆t) 35°c.

PRACTICE. At the top are present 2 lids that allow access to the

tank and the top of the pellet boiler for cleaning.

MAINTENANCE. the procedures for cleaning the interior of the

boiler are made very simple and quick thanks to:

- Ash drawer which is accessed by opening the main door.

- Ash drawer protected by a secondary removable casing pressu-

re at the bottom of the thermostoves front seat collects the waste

from the combustion of the 2nd, 3rd and 4th round of smoke, all

without having to disassembre parts of stoves.

- top cover that gives access to the exchangers of all smoking

tours. Included the cleaning brush for all the internal heat ex-

changer.

the particular location of the circulator, placed at the rear, al-

lows the control and the release of that without having to move

or disassemble any part of the stoves.

MATERIALS AND THICKNESSES. the strong steel structure of

the boiler ensures long durability.

As required by law, the thickness of the plates in contact with fire

and water are of 5 mm and those in contact with water 4 mm.

OPERATION. thanks to the 7 powers of combustion and to main-

tain that form, you can always find the right climatic comfort.

exploiting the 4 smoking lap we have high efficiency up to 94%

and a low temperature of the fumes.

DOMESTIC HOT WATER (on request Cod. 0153 sIst/P). speci-

fic kit for the production of domestic hot water heat exchanger

composed of plates, diverter valve and flow meter, capable of

produce a continuous flow at maximum power of 700 lt / hour

with heat jump of 35 ° C.

6

ELETTRONICA. Pannello comandi grafico di ultima generazione,

in grado di visualizzare in un’unica schermata tutte le principa-

li funzioni della termostufa. Grazie a menu’ chiari e descrittivi le

normali operazioni di controllo e impostazioni delle principali fun-

zioni vengono rese semplici e intuitive.

CRONOTERMOSTATO. Di serie è presente un completo cronoter-

mostato a 3 programmi, giornaliero, settimanale e week-end. Per

ogni giorno è possibile sfruttare fino a 3 accensioni e spegnimenti.

INGRESSO GSM. Possibilità di gestire in remoto le accensioni e gli

spegnimenti della termostufa grazie all’ingresso GSm.

ELECTRONICS. switchboard graph of last generation that can

display on one screen all the main functions of the stoves.

thank menu ‘clear and descriptive normal control and settings

of the main functions are made simple and intuitive.

CHRONOTHERMOSTAT. series is a complete 3-thermostat pro-

grams, daily, weekly and week-end. For every day you can take

advantage up to 3 power key.

INPUT GSM. Ability to remotely manage the switch on and off all

the stoves through the entry of Gsm.
