PelleT

PelleT

INNOVAZIONE - TECNOLOGIA - QUALITA’

INNovAtIoN - teChNoloGY - QUAlItY ‘

QUARZO TEK sono caldaie automatiche a pellet

da locale tecnico. Secondo normativa eN 303-5.

QUARZO LIVING sono termostufe

automatiche a pellet per grandi ambienti.

Secondo norma eN 14785.

elevata efficienza energetica, con funzionamento

automatico in grado di gestire la potenza

erogata compresa dal 30 al 100%.

Elettronica. centralina con autodiagnosi

dello stato di funzionamento e display con

segnalazione delle anomalie. regolazione

automatica della combustione in funzione

delle richieste sia dell’impianto termico che

della temperatura ambiente (solo per liviNG),

cronotermostato e ingresso termostato

ambiente e possibilità di gestione di diversi

tipologie di impianto con accumulo.

Rivestimento. mantellatura esterna in acciaio

verniciato a polvere, corpo caldaia dotato

di doppia porta in acciaio con isolamento

termico in vermiculite dello spessore di 25mm

con spioncino in vetro ceramico da 4mm

(versionei Tek) o grande vetro ceramico da

4mm (versioni liviNG) entrambe resistente

ad 800°c per la visione della fiamma.

QUARTZ TEK are automatic pellet boiler for

technical local. according to standard eN 303-5.

quarTz liviNG are automatic pellet

thermostoves for large environments.

according to standard eN 14785.

high energy efficiency, with automatic

performance able to manage the power

delivered understood by the 30 to 100%.

Electronics. control unit with self-diagnosis

display with anomalies reporting.

automatic adjustment of combustion as a

function of the heating system is required

as well as the ambient temperature (only

for living), thermostat and thermostat input

environment and the possibility of managing

different types of systems with storage.

Coating. The heater casing is coated with

powder-coated steel exterior; the boiler body is

equipped with dual steel door with vermiculite

insulation thickness of 25mm with peephole

ceramic glass 4mm thickness (only for Tek),

large ceramic glass 4mm (only for liviNG)

resistant to 800 ° c for the vision of the flame.

MADE IN ITALY

Versioni. Tek / liviNG e Tek-S / liviNG-S sono

dotate di un particolare bruciatore breveTTaTo

completamente estraibile ad aria soffiata con

braciere in acciaio inox e convogliatore piramidale

caduta/recupero pellet. Solo la versione Tek

/ liviNG sono dotate del sistema automatico

di pulizia del bruciatore con riversamento dei

prodotti della combustione direttamente nel

cassetto cenere. la versione Tek-N / liviNG-N

hanno la tradizionale camera di combustione in

aspirazione dotata di crogiolo in acciaio inox.

Interno. corpo caldaia a 4 giri di fumi, focolare

in acciaio dello spessore di 5mm, caricamento

automatico del pellets a mezzo coclea con

motore esterno al serbatoio combustibile.

Pulizia. Grazie a 3 portelli d’ispezione sul frontale,

uno superiore e ad un grande cassetto cenere, le

fasi di pulizia risultano estremamente semplici.

Versions. Tek / liviNG and Tek-S / liviNG-S

are equipped with a special burner PaTeNTeD

completely removable air burner with stainless

steel grate and conveyor pyramid Pellet.

only the version Tek / liviNG are equipped

with the automatic cleaning system of the

burner with repayment of the combustion

products directly into the ash drawer.

The version. Tek-N / liviNG-N have

the traditional combustion chamber in

suction equipped with inox brazier.

interior. body boiler with 4 flue ways,

fireside in steel with a thickness of 5mm,

automatic loading of the pellets through

auger motor with external fuel tank.

Cleaning. Thanks to the 3 inspection doors on

the front more than one and a single large ash

tray, the cleaning steps are extremely simple.
