415

=

=

Breite

Two different washbasin heights:

Standard: 100 mm; with long basin: 120 mm

2 pieces mounting bracket already included

in the scope of delivery

Washbasin mineral cast gelcoat,

angular, white/slate

•

Angular basin

•

With gelcoat coating

•

Colour: white/slate

•

Without overflow

•

With tap hole Ø 35 mm

•

With 2 pieces mounting angle

Dimensions

Washbasin (WxHxD): 500-1600x100x460 mm

Basin (WxHxD):

415x80x255 mm

Tap hole:

Ø 35 mm

Note:

Overflow available at no additional charge.

White with slate structure

Description

Colour

Width

Article number

Washbasin mineral cast gelcoat, angular

White / Slate

500 mm

CONW2111120500

Washbasin mineral cast gelcoat, angular

White / Slate

700 mm

CONW2111120700

Washbasin mineral cast gelcoat, angular

White / Slate

800 mm

CONW2111120800

Washbasin mineral cast gelcoat, angular

White / Slate

900 mm

CONW2111120900

Washbasin mineral cast gelcoat, angular

White / Slate

1000 mm

CONW2111121000

Washbasin mineral cast gelcoat, angular

White / Slate

1100 mm

CONW2111121100

Washbasin mineral cast gelcoat, angular

White / Slate

1200 mm

CONW2111121200

Washbasin mineral cast gelcoat, angular

White / Slate

1400 mm

CONW2111121400

Washbasin mineral cast gelcoat, angular

White / Slate

1600 mm

CONW2111121600

Washbasin mineral cast gelcoat, angular, white/slate, width 500-1600 mm

CONTI Sanitärarmaturen GmbH | Hauptstraße 98 | 35435 Wettenberg | Germany | phone +49 641 98221 0 | fax +49 641 98221 50

342

info@conti.plus | www.conti.plus | CONVKF1010EN | valid from 07/2021 | Subject to change without prior notice
