CHAPTER 2 DEVICES FOR GAS

70600F/6B

Aluminium gas filter; long-life filter element with high dust-absorption composed of two Viledon

P15/500S panels approved to DIN EN779; synthetic filter cage with penetration-resistant steel

reinforcement; NBR cover O-ring. Suitable for manufactured gas, natural gas, liquefied petroleum

gas (LPG), non-aggressive gas and air. PN 6 with 2 tapping points. Filtration rating: 50 μm. Operating

temperature range: -20 to 80°C.

Type

70603F/6B

70631F/6B

70610F/6B

70620F/6B

70640F/6B

70650F/6B

70660F/6B

Part no.

007.0050.100

007.0051.100

007.0052.200

007.0053.200

007.0054.100

007.0055.100

007.0056.100

Dimensions on page 333

70680

Connections

Q.ty/Box

DN 40

1

DN 50

1

DN 65

1

DN 80

1

DN 100

1

DN125

1

DN150

1

Box/Carton

1

1

1

1

1

1

1

€/unit

High-efficiency aluminium gas filter; polyester felt filter element;

manufactured gas, natural gas, liquefied petroleum gas (LPG),

Filtration rating: 5 μm.

Operating temperature range: -20 to 80°C.

aluminium mesh cage. Suitable for

non-aggressive gas and air. PN 6.

Type

70684

70685

70686

70687

Part no.

007.0012.000

007.0013.000

007.0014.000

007.0015.000

Dimensions on page 333

PARTS AND ACCESSORIES

Connections

1”

1.1/4”

1.1/2”

2”

Q.ty/Box

Box/

Carton

1

1

1

1

1

1

1

1

€/unit

Type

Part no.

Description

Q.ty/

Box

Box/

Carton

€/unit

70516

014.0053.000

Wall-mounting bracket

1

1

3215

014.0090.001

Kit comprising filter cartridge and cover O-ring for 70609 and 70608

1

1

3216

014.0091.001

Kit comprising filter cartridge and cover O-ring for 70611/1B and 70612/1B

1

1

3217

014.0092.001

Kit comprising filter cartridge and cover O-ring for 70602/1B, 70603/1B and

70604/1B

1

1

3218

014.0093.001

Kit comprising filter cartridge and cover O-ring for 70631/1B

1

1

3219

014.0094.001

Kit comprising filter cartridge and cover O-ring for 70603F/6B

1

1

3220

014.0095.001

Kit comprising filter cartridge and cover O-ring for 70631F/6B

1

1

3226

014.0104.000

Kit comprising filter cartridge and cover O-ring for 70610F/6B and

70620F/6B

1

1

3223

014.0098.001

Kit comprising filter cartridge and cover O-ring for 70640F/6B

1

1

3225

014.0099.001

Kit comprising filter cartridge and cover O-ring for 70650F/6B

1

1

3224

014.0100.001

Kit comprising filter cartridge and cover O-ring for 70660F/6B

1

1

3216/6B

014.0091.002

Kit comprising filter cartridge and cover O-ring for 70611/6B and 70612/6B

1

1

3217/6B

014.0092.002

Kit comprising filter cartridge and cover O-ring for 70602/6B, 70603/6B

and 70604/6B

1

1

3218/6B

014.0093.002

Kit comprising filter cartridge and cover O-ring for 70631/6B

1

1

60680

014.0042.000

Kit comprising filter cartridge and cover O-ring for 70684, 70685 and

70686

1

1

60687

014.0043.000

Kit comprising filter cartridge and cover O-ring for 70687

1

1

1639

014.0006.001

1/8” test point (pack of 100 pcs.)

100

100

1639

014.0006.002

1/8” test point (pack of 1,000 pcs.)

1000

1000

1640

014.0007.001

1/4” test point (pack of 100 pcs.)

100

100

1640

014.0007.002

1/4” test point (pack of 1,000 pcs.)

1000

1000

6
