CHAPTER 2 DEVICES FOR GAS

ST1B

Flanged aluminium pressure regulator to EN 88-2. Max. inlet pressure 1 bar. Max. outlet pressure

450 mbar, 200 mbar for STR DN 125-150. Closure control. Suitable for manufactured gas, natural

gas, liquefied petroleum gas (LPG), non-aggressive gas and air. Operating temperature range: -15

to 60°C.

Type

ST1B65

ST1B65

ST1B65

ST1B65

ST1B65

ST1B80

ST1B80

ST1B80

ST1B80

ST1B80

ST1B100

ST1B100

ST1B100

ST1B100

ST1B100

ST1B125

ST1B125

ST1B125

ST1B125

ST1B125

ST1B150

ST1B150

ST1B150

ST1B150

ST1B150

Part number

Connec-

tions

Description

With neutral spring 10-30 mbar

With red spring 25-80 mbar

With purple spring 60-120 mbar

With blue spring 100-220 mbar

With white spring 200-450 mbar

With neutral spring 10-30 mbar

With red spring 25-80 mbar

With purple spring 60-120 mbar

With blue spring 100-220 mbar

With white spring 200-450 mbar

With neutral spring 10-40 mbar

With red spring 30-70 mbar

With purple spring 60-110 mbar

With brown spring 100-210 mbar

With white spring 200-450 mbar

With neutral spring 10-30 mbar

With red spring 25-75 mbar

With brown spring 70-120 mbar

With white spring 110-170 mbar

With black spring 140-200 mbar

With neutral spring 10-30 mbar

With red spring 25-75 mbar

With brown spring 70-120 mbar

With white spring 110-170 mbar

With black spring 140-200 mbar

Q.ty/ Box/

Box Carton

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

€/unit

009.0270.201

009.0270.203

009.0270.204

009.0270.206

009.0270.207

009.0271.201

009.0271.203

009.0271.204

009.0271.206

009.0271.207

009.0272.201

009.0272.203

009.0272.204

009.0272.205

009.0272.207

009.0273.001

009.0273.003

009.0273.005

009.0273.007

009.0273.006

009.0274.001

009.0274.003

009.0274.005

009.0274.007

009.0274.006

Dimensions on pages 336-337

PARTS KIT

DN 65

DN 65

DN 65

DN 65

DN 65

DN 80

DN 80

DN 80

DN 80

DN 80

DN100

DN100

DN100

DN100

DN100

DN125

DN125

DN125

DN125

DN125

DN150

DN150

DN150

DN150

DN150

Type

Part number

Regulators

Description

Q.ty/Box

Box/

Carton

€/unit

3235

014.0500.001

FGD, FGDR, FG1B 15 - 20 - 25

Kit comprising filter cartridge

and cover O-ring

1

1

3236

014.0501.001

FGD, FGDR, FG1B 32 - 40 - 50/40

Kit comprising filter cartridge

and cover O-ring

1

1

3233

014.0153.001

FGD, FGDR, FG1B 50

Kit comprising filter cartridge

and cover O-ring

1

1

3234

014.0155.001

FSDR, FS1B 65 - 80

Kit comprising filter cartridge

and cover O-ring

1

1

3286

014.0502.001

FGD, FGDR, FG1B 15 - 20 - 25

Servicing components kit

1

1

3287

014.0503.001

FGD, FGDR, FG1B 32 - 40 - 50/40

Servicing components kit

1

1

3262

014.0190.002

FGD, FGDR, FG1B 50

Servicing components kit

1

1

3295

014.0295.000

FSDR, FS1B 65 - 80

Servicing components kit

1

1

3296

014.0296.000

STR, ST1B 65 - 80

Servicing components kit

1

1

3297

014.0297.000

STR, ST1B 100

Servicing components kit

1

1

3504

014.0572.000

STR, ST1B 125 - 150

Servicing components kit

1

1
