1

Screw

2

T handle

3

O-RIng

4

O-Ring

5

Stem

6

End adapter

7

Seat

8

Ball

9

Body

pos.

1

2

3

4

5

6

7

8

9

maTErIal

Zinc-plated steel Fe CB4

Varnished aluminium

VITON

®

NBR

Brass CW614N

Nickel-plated brass CW617N

P.T.F.E.

Chrome-plated brass CW617N

Nickel-plated brass CW617N

CH

DImEnsIons (mm)

Dimension Dn

a

b

c

D

E

f

cH

1/4”

8

56,9 23,5 37,3

3/8”

10

58,9

24

37,3

1/2”

15

68

30,5 48,8

3/4”

20 75,5 37 46,8

1”

25 90,5 45,5 50,8

47

8

11

18

47

10

11,4

21

54

15

15

25

62

20

16,3

31

62

25 19,1 38

1

2

4

3

5

6

7

9

8

DEscrIpTIon

n

Screw

1

T handle

1

O-Ring

1

O-Ring

1

Stem

1

End adapter

1

Seat

2

Ball

1

Body

1

CH

B

E

C

F

F

A

D
