ACCESSORI | ACCESSORIES

EXTENSION KIT (4 pezzi | pieces)

Kit per allungamento fianco copri unità ventilante esterna costituito da 4 distanziali in acciaio zincato verniciato di forte spessore.

L’accoppiamento al fianco avviene tramite vite metrica su innesto filettato posto sul distanziale.

Kit for extending the side cover of the external fan unit consists of 4 thickly galvanized and painted steel spacers. The connecting to the side is

done through metric screws on a thread coupling placed on the spacer.

A mm

B mm

100

115

SUPPORTING FEET KIT (4 pezzi | pieces)

Kit piedini regolabili in gomma nera naturale comprendenti 4 elementi antivibranti con relative rondelle e dadi. Filetto Ø 8 mm.

Adjustable feet kit in natural black rubber including 4 anti-vibration elements with corresponding washers and nuts. Thread Ø 8 mm.

C mm

55

VERSIONI DISPONIBILI | VERSIONS AVAILABLE

Taglia | Size

S

M

L

XL

XL1

ACCESSORI | ACCESSORIES:

Taglia | Size

S

M

L

XL

XL1

Foil (bottom)

Back

Exstension Kit (4 pezzi | pieces)

Supporting feet kit (4 pezzi | pieces)

785

B

A

C

C

O

V

E

R
