DISEGNI | DRAWINGS

L

M

N

C

O

F

X

G

F

Y

X

Y

C

L

M

F

G

N

O

S

mm

mm

mm

mm

mm

mm

mm

mm

mm

mm

B-5

H-5

300

75

225

25

88

H/2-80 H/2-230 25

TABELLA PRESTAZIONI | PERFORMANCE TABLE

Serrande tagliafuoco testate secondo EN 1366-2 e classificate secondo EN 13501-3

Fire dampers tested according EN 1366/2 and classi

fied according to EN 13501-3

Classificazioni di resistenza | Classification of resistance

Muratura in calcestruzzo cellulare aerato spessore 100 mm

Aerated concrete wall thickness 100 mm

(v

e

io)

LEGENDA | LEGEND

EI 120 S - 500 Pa

da 100x200 a 800x600

from 100x200 to 800x600

EI 90 S - 500 Pa

da 100x200 a 800x600

from 100x200 to 800x600

ve

ho

i  o

Pa

E

I

S

= installazione verticale - vertical installation

= installazione orizzontale - horizontal installation

= lato esposto al fuoco indifferente - side esposed to fire indifferent

= Pascal - Pascal

= integrità - entirety

= isolamento termico - thermal insulation

= tenuta ai fumi - smoke seal
