CVAV

INSTALLAZIONE | INSTALLATION

Per evitare errori nella misurazione della portata seguire queste regole di installazione.

In order to avold mistakes in air

flow measuring one should follow these rules when installing.

min. 2xDn

min. 2xDn

TABELLA DI SELEZIONE | TECHNICAL DATA

Ø

mm

100

125

160

200

250

315

355

400

Portata aria | Air flow rate m

3

/h

L’incertezza nella misura a 1,2 m/s è 22% a 12 m/s

è 4% | Uncertainly in the measure at 1,2 m/s is 22% at 12 m/s is 4%

SILENZIATORI | SILENCER CVAVS

Manicotto zincato femmina | Female galvanized sleeve

Ø

L

mm

mm

100

900

125

900

160

900

200

900

250

900

315

900

355

900

400

900

682

Minimo | Minimum

S 1,2 m/s

34

53

87

138

212

337

428

543

Massimo | Maximum

S 12 m/s

340

530

870

1380

2120

3370

4280

5430
