EFI

660

Caratteristiche: serranda a iride.

Costruzione: acciaio zincato.

Impiego: su canale circolare per regolazione e misurazione.

Fissaggio: ad innesto.

Characteristics: iris damper.

Finishing: galvanized steel.

Utilization: on circular duct for regulation and measurement.

Fixing: by coupling.

DISEGNI | DRAWINGS

Ød Ød

2

ØD

L

REGOLAZIONE POSION

REGOLAZION0EREP1GOOS2LIOA3NZIO4N5E P6OS7IO8N

0 1 62

7

3 4 05 16 27 38 4 5 6 7 8

ØD ØD

L

L

5

67 4

5

5

67

4

4

1 Prese di pressione | Detecting pressure points

2 Leva di regolazione | Adjustament lever

Misura | Size

100

125

160

200

250

315

Ø d

ØD

99

165

124

210

159

230

199

285

249

335

314

410

L

Peso | Weight Kg

110

0,5

110

0,7

110

0,9

110

1,4

135

2,1

135

3,5

Ød

1

1

2

2

1

R

E
