DISEGNI | DRAWINGS

115

115

115

 SCSM

 GRASMF

HxB 1

HxB 1

HxB 1

(B-15)x(H-15)

(B-15)x(H-15)

(B-15)x(H-15)

(B+35)x(H+35)

(B+35)x(H+35)

(B+35)x(H+35)

22

2

33

3

115

4545 5454

45 54

I

R

G

1

Dimensioni foro | Hole dimension

2

Cricchetto per apertura push-pull | Ratchet for opening push-pull

3

Assieme con piastrina per apertura push-pull | Assembly with plate for push-pull opening

4

Vano alloggiamento filtro (filtro 512x512) | Filter housing compartment (filter 512x512)

44

4

DIMENSIONI FILTRO | FILTER DIMENSIONS

Dimensione - Dimension B

H

200

300

400

500

600

800

1000

mm

mm

mm

mm

mm

mm

mm

mm

200

152x152

300

152x252

400

152x352

500

152x452

600

152x552

252x152

252x252

252x352

252x452

252x552

352x152

352x252

352x352

352x452

352x552

452x152

452x252

452x352

452x452

452x552

552x152

552x252

552x352

552x452

552x552

752x152

752x252

752x352

752x452

752x552

952x152

952x252

952x352

952x452

952x552

15 25

15 25

15 25

4

GRASMF
