RUBINETTI RAPIDI | QUICK COUPLERS | RACCORDS RAPIDES | SCHNELLKLUPPLUNGEN

16/AM | 16/BM METAL

RUBINETTO RAPIDO UNIVERSALE A SFERE CON PORTAGOMMA | BEARING-TYPE UNIVERSAL QUICK COUPLER WITH SLEEVE FOR RUBBER HOSE

RACCORD RAPIDE UNIVERSEL A BILLES AVEC PORTE-TUYAU | UNIVERSAL-SCHNELLKUPPLUNG MIT GUMMISCHLAUCHHALTER

COD.

MOD.

Di X De

AH025929S 16/AM ø 6 x 14 10

AH025928S 16/BM ø 8 x 17 10

17/AM | 17/BM METAL

RUBINETTO RAPIDO UNIVERSALE A SFERE FILETTATO MASCHIO

MALE THREADED BEARING-TYPE UNIVERSAL QUICK COUPLER

RACCORD RAPIDE UNIVERSEL A BILLES FILETE MALE

UNIVERSAL-SCHNELLKUPPLUNG MIT AUSSENGEWINDE

17/CM | 17/DM METAL

RUBINETTO RAPIDO UNIVERSALE A SFERE FILETTATO FEMMINA

FEMALE THREADED BEARING-TYPE UNIVERSAL QUICK COUPLER

RACCORD RAPIDE UNIVERSEL A BILLES FILETE FEMELLE

UNIVERSAL-SCHNELLKUPPLUNG MIT INNENGEWINDE

AH025914S 17/CM 1/4 F 10

AH025915S 17/DM 3/8 F 10

AH025938S 17/DM 1/2 F 10

COD.

MOD.

F

COD.

MOD.

F

AH025911S

AH025912S

AH025913S

17/AM 1/4 M 10

17/BM 3/8 M

17/BM 1/2 M

10

10

17/EM METAL

RUBINETTO RAPIDO UNIVERSALE A SFERE CON RESCA | DUAL PIN UNIVERSAL QUICK COUPLER WITH TAILPIECE

RACCORD RAPIDE UNIVERSEL A BILLES AVEC PORTE-TUYAU A EPI | UNIVERSAL-SCHNELLKUPPLUNG MIT SCHLAUCHTÜLLE

COD.

MOD.

F

AH025933S

AH025930S

AH025934S

17/EM ø 6 10

17/EM ø 8 10

17/EM ø 10 10

6
