VANTAGGI

ADVANTAGES

• Impianto idrico in soli 8CM: cassetta dagli ingombri

contenuti per adattarsi ai nuovi standard costruttivi.

• Fornito completo di staffe per il fissaggio sulla

muratura.

• Connessioni 3/4 EUROCONO su tutti gli attacchi con

possibilit

à di utilizzare sia raccordi a stringere che a

pressare.

• Rubinetti a sfera smontabili frontalmente con

passaggio totale per una manutenzione facilitata.

• Uscite calda e fredda alternate che permettono di non

incrociare le tubazioni.

• Possibilit

à di installazione sia con coperchio di

ispezione che totalmente nascosto.

• Posizionamento verticale ed orizzontale, configurabile

da 3 a 5 uscite per temperatura.

• Realizzazione pratica e sicura di un sistema di

distribuzione idrica in cui tutte le parti che lo

compongono sono protette ed isolate dal contatto

diretto con la muratura.

• Tre diverse soluzioni per il comando dei rubinetti

d’intercettazione permettono di adattarsi a qualsiasi

esigenza estetica.

• A water distribution system in just 8 CM: the small case

adapts to new construction standards.

• Supplied complete with brackets for fixing to masonry.

• 3/4 EUROCONE connections on all couplings with the

possibility of using both compression and press

fittings.

• Front-mountable full-bore ball valves for easy

maintenance.

• Alternate hot and cold outlets that allow the pipes not

to cross.

• Possibility of installation both with inspection cover and

totally hidden.

• Vertical and horizontal positioning, configurable from 3

to 5 outlets per temperature.

• Practical and safe construction of a water distribution

system in which all its component parts are protected

and isolated from direct contact with the masonry.

• Three different solutions for the control of the shut-off

valves allow it to be adapted to any aesthetic need.

CAMPI DI APPLICAZIONI E PRESTAZIONI

FIELDS OF APPLICATION

APPLICAZIONI

APPLICATIONS

T. min.

T. max

Press.max

Max. pressure

acqua potabile

drinking water

-20°C

+70°C

10 bar

acqua calda sanitari

hot sanitary water

-20°C

+70°C

10 bar
